| Model |
XLB-500*500*2/XLB-D500*500*2 |
| Total Pressing Force(KN) |
630/630 |
| Maximum Working Fluid Pressure(Mpa) |
20/20 |
| Distance Between Heating Plates(mm) |
125/125 |
| Size of Heating Plate(mm) |
500*500/500*500 |
| Plate Heating Mode |
Steam/Electricity |
| Steam Pressure(Mpa) |
|
| Electric Heating Capacity(KW) |
13.2 |
| Plunger Stroke(mm) |
250/250 |
| Pressing Force of Heating Plate(Mpa) |
2.5/2.5 |
| Motor(KW) |
3\3 |
| Overall Dimensions(mm) |
1400*1000*1750/1400*1000*1750 |
| Net Weight(Kg) |
2000/2000 |
| |
|
