| 型号 |
YAPB2-30H |
YAPB2-38H |
YAPB2-45H |
YAPB2-53H |
YAPB2-78H |
YAPB2-95H |
| A26/W26°C加热能力 |
W |
3600 |
4600 |
5200 |
6200 |
8200 |
11000 |
| A7/W27°C加热能力 |
W |
2500 |
2770 |
3500 |
3800 |
5600 |
6700 |
| 额定制热量 |
W |
3000 |
3800 |
4500 |
5300 |
7800 |
9500 |
| BTU |
10200 |
13000 |
15300 |
18000 |
26500 |
32500 |
| 额定输入功率 |
W |
729 |
930 |
1050 |
1250 |
1650 |
2230 |
| 额定输入电流 |
A |
3.3 |
4.3 |
5 |
5.7 |
7.5 |
10.6 |
| 电源 |
V/Ph/Hz |
220V/1Ph/50Hz |
| 控制器 |
|
Mechanical Controller |
| 冷凝器 |
|
PVC With Titanium |
| 压缩机数量 |
|
1 |
| 压缩机类型 |
|
Rotary |
| 噪声 |
dB(A) |
48 |
| 水连接 |
mm |
50 |
| 水流量 |
m³/h |
3-5 |
3-5 |
4-6 |
4-6 |
4-7 |
4-7 |
| 水压降 |
kpa |
10 |
10 |
10 |
12 |
12 |
15 |
| 尺寸L*w*h |
mm |
770*300*490 |
936*360*550 |
936*360*550 |
936*360*550 |
936*360*550 |
1010*370*615 |
| 包装尺寸L*w*h |
mm |
820*315*525 |
1090*390*580 |
1090*390*580 |
1090*390*580 |
1090*390*580 |
1170*415*645 |
| 毛重/净重 |
kg |
29/32 |
32/35 |
36/39 |
39/42 |
54/57 |
63/67 |
